Your Professional Inline Precision Planetary Reducer Supplier
Guomao Group has been a manufacturer specializing in power transmission industry for 30 years with a wide product series including speed reducer boxes, gear motors, electric motors and become a bellwether in the intelligent automation.Xinjian Transmission Machinery, as one of its subsidiary sales company responsible for overseas marketing, commit itself to exploring the world market and introduction of GUOMAO's products to more potential customers. We can also provide new or upgrading solutions of tailored power-transmission machines to fit into your systemic application.
Why Choose Us
Production Market
With a strong focus on export markets, we have successfully captured significant market share in South America, Mid East, the Eastern Asia, Domestic Market, and South Asia.
Wide Range of Applications
Our products are widely used in Garment Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Printing Shops, Construction works, Energy & Mining, Food & Beverage Shops, Hotels, Building Material Shops, Farms, Restaurant, Home Use, Retail, Food Shop, Advertising Company, Energy & Mining, Other.
Quality Assurance
Our Each batch of goods has a corresponding quality inspection report to solve your concerns about product quality.
Quick Transportation
We cooperate with professional sea, air and logistics companies to provide you with the best transportation solution.
Advantages of Inline Precision Planetary Reducer
High power density
One of the biggest advantages of planetary gearboxes is their high power density. They can transmit high torques at high speeds without taking up much space. This makes them ideal for applications where space is limited and high power density is required.
Smooth and quiet operation
Planetary gearboxes have multiple teeth in contact at all times, which results in smooth and quiet operation. This makes them ideal for applications where noise and vibration are a concern, such as in the automotive industry.
High efficiency
Planetary gearboxes have high efficiency due to their multiple gear sets. This also means that they require less maintenance and have a longer lifespan compared to other types of gearboxes.
Versatility
Planetary gearboxes are versatile and can be used in a wide range of applications, including robotics, aerospace, and medical equipment. They can also be combined with other gearboxes to create hybrid systems that have even more advantages.
Components of a Inline Precision Planetary Reducer
Sun Gear
Central gear on the input shaft that drives the system, usually a standard component in many gear systems.
Planet Gear
Multiple gears orbiting the sun gear, while meshing with the sun and ring gears.
Ring Gear
Outer gear with internal teeth that typically remains stationary.
Planet Carrier
Holds the planet gears and connects to the output shaft.
Technical parameters
|
Ratio |
3.41-289.74 |
|
Input power |
0.12-160KW |
|
Output torque |
61-23200N.m |
|
Output speed |
5-415rpm |
|
Mounting type |
Foot mounted, flange mounted, foot and flange mounted, single-stage foot mounted, single stage flange mounted, Flange-mounted with extended bearing hub |
|
Input Method |
Flange input(AM), shaft input(AD), inline AC motor input, or AQA servo motor |
|
Brake Release |
HF-manual release(lock in the brake release position), HR-manual release(autom-atic braking position) |
|
Thermistor |
TF(Thermistor protection PTC thermisto) |
|
Mounting Position |
M1, M2, M3, M4, M5, M6 |
|
Type |
R17-R167 |
|
Output shaft dis. |
20mm, 25mm, 30mm, 35mm, 40mm, 50mm, 60mm, 70mm, 90mm, 110mm, 120mm |
|
Housing material |
HT200 high-strength cast iron from R37,47,57,67,77,87 |
|
Housing material |
HT250 High strength cast iron from R97 107,137,147,157,167,187 |
|
Heat treatment technology |
Carbonitriding and hardening treatment |
|
Efficiency |
92%-97% |
|
Lubricant |
VG220 |
|
Protection Class |
IP55, F class |
Applications of Inline Precision Planetary Reducer
01
Automotive
Ensures smooth, reliable operation in automatic transmissions.
02
Robotics
Provides compact and precise motion control for advanced robotics.
03
Industrial Machinery
Handles heavy loads in conveyors, mixers, and cranes.
04
Wind Turbines
Facilitates efficient energy transfer in renewable energy systems.
Delivery
FAQ
We're professional inline precision planetary reducer manufacturers and suppliers in China. We warmly welcome you to wholesale high quality inline precision planetary reducer made in China here from our factory. For customized service, contact us now.
